The Best Hardware Configuration for SolidWorks CAD Software

Posted by cadhardware

Nov 10, 2011, 3:55:05 PM

SolidWorksOptimizing hardware for SolidWorks is essential for getting the most out of this heavy-hitting CAD application, as we've discussed on CADspeed previously. So we were thrilled when the SolidWorks forum addressed this very issue recently on their forums.

The key to getting the most out of SolidWorks, or any CAD application for that matter, is ensuring your hardware can handle the workload. Remember that your situation is unique. In simple terms, two users using the same software on the same system may have very different perspectives on their workload efficiency if one is using 3D rendering and the other is not. Consider your needs first and foremost.

On the flip side, if you know you need new hardware, simply buying the most expensive machine may not pay off in the long run either. Think in terms of your productivity while shopping for a new workstation to get the most for your budget, hopefully with a little room to grow for those inevitable upgrades.

That said, here's a summary of the recommendations straight from SolidWorks themselves.

RAM (Random-Access Memory)

The amount of RAM you need depends less on SolidWorks and more on the number of applications you run at the same time, plus the size and complexity of your SolidWorks parts, assemblies and drawings. SolidWorks recommends you have enough RAM to work with your common applications (i.e., Microsoft Office, email, etc.) and load your SolidWorks documents at the same time.

The recommended RAM for the current SolidWorks versions is 6GB. That should be your starting point. For more information on how much RAM you need, here's a great resource on the SolidWorks forums.

CPU

Processor speed is another key factor when selecting the right hardware for you. It's hard to sort through all the different options though, so we recommend testing a system with your actual models. SolidWorks also offers a helpful Performance Test, which offers a standardized test for determining performance of your major system components (i.e., CPU, I/O, video) when working with SolidWorks datasets. Even better, when you complete the SolidWorks Performance Test, you have an option to share your score with others. This gives you, and other community members, a sense of where a system stands relative to others. Nice!

Note that SolidWorks and some of its add-ons (PhotoView 360) have some multithreaded capabilities, so the application can use the second processor or multiple cores. But SolidWorks says that rebuilds are single threaded and therefore rebuilds generally will not be faster with multiple CPUs or cores.

Disk

The size of your hard drive or solid-state drive should be based on the disk space you need. Take a look at all your system's components: operating system, applications and documents. If you work primarily on a network, your needs may be different than those who primarily use their local drive. Don't forget to develop a back-up plan for your data, if you don't already have one. (You do have one, right?)

Graphics Cards

The very nature of CAD software requires a good workstation-level graphics card and driver. You are probably going to need at least a mid-range card, if not a high-end card, depending on the type of CAD work you do. For graphics cards, we recommend starting with the SolidWorks Certified Graphics Cards and System, because SolidWorks has done the testing for you.

Can't get enough about hardware configurations for SolidWorks? Check out this great post from SolidWorks on their forums. Or learn more about the minimum requirements for SolidWorks.

Topics: Workstations, RAM, SolidWorks, Hardware, Graphics Card, Multi-Threading, Hard Drive, Processors, SSD Drive, GPU, Memory, Graphics Cards, Backup System, Video Cards, CAD
