A CAD Dinosaur’s Journey, Part 1: Emerging from the Swamp

Posted by cadhardware

Feb 17, 2015 8:06:00 PM

Editor’s Note: Welcome to Cadalyst's blog series by Patrick Hughes, A CAD Dinosaur's Journey into Modern Times.” In this three-month series, Hughes chronicles his transition from AutoCAD R14 to v2015 and from an outdated PC to a state-of-the-art professional workstation. Follow along and enjoy!



1-acadblog-T-rex-iheartcadAs are most nights here in the swamp, it was dark and stormy. Fortunately, my Internet connection held up. Surfing my favorite CAD sites, I came across an interesting contest sponsored by Cadalyst that just might help me out of this swamp.

It seemed Cadalyst was just itching to give away a professional CAD workstation to someone who submitted the best video explaining his or her need for a more powerful computer.

From the Beginning

Let’s back up a bit. Allow me to introduce myself: Call me T, short for T-Rex, short for Tyrannosaurus Rex. Yes, I’m a dinosaur. You see, for the longest time I’ve used AutoCAD R14 — yes, the original R14 — for all my machine design work. R14 was very capable and served my purpose, but as time passed, and as the days and weeks continued their relentless passage, I felt more and more mired in the swamp of obsolescence.

Perhaps this contest would be my ticket into modern times. My walnut-sized brain spun into high gear as I crafted my video submission and lo and behold, my video was a winner. Woo hoo! Or, as we say in dinosaur parlance, "Rawrrr."

The new, state-of-the art professional workstation was going to change history for this T-Rex — but it was only part of the solution. To emerge fully from the swamp, I would need modern CAD software as well. But how could I afford it? A new version of AutoCAD would cost a pretty penny.

So, I pitched an idea.

If Cadalyst could persuade Autodesk to supply a copy of AutoCAD 2015, the latest version of the software, I would gladly write a series of articles journaling my transition from AutoCAD R14 to 2015, sharing my experience and the benefits gained by moving out of the technological dark ages and into modern times. It could be a win–win–win for Cadalyst, Autodesk, and T.

You can imagine my big-toothed grin when the idea was met enthusiastically and I was given the thumbs-up to proceed.

Join the T Team

Being the dinosaur I am, I would be relatively content to apply my new software to my old work style. But the purpose of upgrading to new software is to learn the new tools and, more importantly, to put them to productive use.

I’ve got a good idea about the things I want to improve upon and how I might use the new tools. But this technological transition is a tall order, especially for a guy with short arms, so I invite you to participate in my journey. How can you help? Well, I’m glad you asked. I’m guessing a number of you are currently working with an older release of AutoCAD with an eye on upgrading. I’m confident most of you work in different engineering fields than I do and use AutoCAD in vastly different ways. AutoCAD 2015 holds new features that don’t interest me but would likely appeal to you. Send me your suggestions! Maybe I could actually use those tools — or at least I could experiment with them in new and exciting ways.

So, I invite you to send me your questions about things you may have heard about in modern AutoCAD. I’ll do my best to explore them, and in that way add you to the “win” equation.

_________________

Stick around and watch original video from Patrick Hughes T:

http://www.youtube.com/watch?v=tb_uiSoMdFE

_________________

About the author: Patrick Hughes, machine designer and owner of Engineered Design Solutions in Rockford, Illinois, has worked with AutoCAD since 1991. He has developed a number of AutoLISP and other software solutions to automate his workflow and increase productivity, including the commercially available time tracking program, CadTempo.

Topics: Workstations, AutoCAD, CAD workstations, A CAD Dinosaur's Journey into Modern Times, CAD
