CADspeed -- Optimizing Hardware for CAD Software

A Look at Vectorworks 2015

Posted by mediashower1

Mar 15, 2015 9:52:16 AM

Is it CAD or BIM? Vectorworks 2015 combines enough of both to satisfy a variety of design and development needs. In all, reviewers and users have been pleased with what they've seen from this new product. It seems to be an improvement over previous versions in several ways (more discussion on this below), and offers some neat new features that can be helpful in a multitude of situations. Here is what you need to know before investing in this version of Vectorworks.

One of the biggest improvements in the 2015 version is 64-bit capabilities across all of the products. The product description states, "We do not consider remote login environments (such as remote desktops, terminal services, or virtual machine environments, such as Parallels and VMware) to be appropriate for regular work, so Vectorworks performance in these situations is not of primary concern to us."

This was concerning to some users who planned to use the product in remote situations or in a cloud environment. However, numerous users have had good success operating Vectorworks 2015 with both the cloud and via remote workstations. The primary concern is connectivity and bandwidth, not any known issues with the product itself. This version is compatible with all of the common modern processors.

The interface will be familiar to most users, a sort of mash up of Photoshop, SketchUp, and MicroStation. Though it was originally designed for use on Apple computers, Vectorworks 2015 looks and acts exactly the same on Windows systems as it does on the Mac. This makes it easy for users to switch between systems and collaborate with others who rely on different systems.

The open GL mode is becoming more common in software developed for CAD workstations, and is well received by users for its easy fly around mode, simplicity in changing viewing modes, seamless virtual walk through mode, and speed in switching between modes and features.

Users are also having fun with the Deform Tool, which allows you to bend solid geometric shapes into user-defined shapes. Though this is more practical for users like furniture designers, it's fun to play around with.

Vectorworks 2015 also features the ability to set text style by class, which allows you to provide more consistency within the documentation. It also allows for the modification of PDF files. You can now import a PDF file and crop it. This is helpful when using only part of a PDF file as a reference, and for including a picture of the product within the design.

Rectangle Wall Mode is another significant improvement which allows you to select a type of wall and create it by simply drawing a rectangle. You can draw curtain walls automatically, without having to input vertical or horizontal mullions. Better yet, if you decide to change the design halfway through, you don't have to begin the entire process over again.

For photorealistic renderings, users can import 3DS and SKI files, such as those found on 3D Warehouse and Turbosquid, or use images provided with Vectorworks, which are somewhat improved over previous versions and render quickly.


Vectorworks The stock images are better, and version 2015 allows you to easily import more images from other sources.

Vectorworks 2015 continues to require large amounts of memory and a fast processor to run. Users who lack a sufficiently equipped workstation have reported problems running out of memory, having to shut down the program, and even sometimes having to reboot the computer.

How Much Does It Cost and What's in the Box?

Expect to pay just under $3,500 for Vectorworks 2015 from most outlets. The Vectorworks 2015 installation DVD, "Let's Get Started" pamphlet, and "Getting Started" DVD come in the box. The all-inclusive product features:

• Vectorworks Architect
• Vectorworks Landmark
• Vectorworks Spotlight
• Vectorworks Machine Design
